- Model: DAAO6604-6
- Size: 1200*1200*3950mm, water tank Size: 1150*1150*1200: customized available
- Material: stainless steel 304 (SS316L is optional)
- Certificate & Standard: ANSI Z 358.1-2016, EN15154.1/2:2006
- Wall Thickness: 1.2mm; Pipe thickness:2.5-3mm
- Function: eye washing, body showering, automatic water inlet and outlet(optional), heating,cooling(optional), sound and light alarm(optional), remote wireless alarm system(optional)
- Working environment temperature: -35 ° C -55 ° C
- Power:220V/380V(customized available)
- Inlet size: NPT 1 1/4″
- Drain size: NPT 1 1/4″
- Eyewash flow rate: ≥11.4L/min
- Shower flow rate: ≥75.7L/min
-Three layers reinforced tank
-Insulation inside
-Water level gauge
-1500L (Customized available)
-Filter include
-Over flow
-Lifting ear
-Anti scald valve (optional)
-Auto water filling (optional)
Shower Head
Based on the American standard requirements and our unique design, one time stamping molding shower head have total 94 holes and the edge is half hole which can create the perfect water spay area.
Pipe &Pull Rod
Good quality 304 stainless steel tube content with more than 8% nickel and wall thickness 3.0mm. Both inside and outside is finished with fine polishing.
Floor
The floor assembled by 2 removable punch plate which have total 234 round holes. With scientific designed, 10mm diameter holes that perfectly ensure the water can be drain in time and prevent other things drop in. Floor divided into two removable pieces which is easily to disassemble and clean.
Eyewash spray head
-One time stamping molding
-ABS plastic combine with seamless 304 stainless steel and
– 3 layers filter
-Flag handle: bright yellow. Easy to recognize from far distance.
Wall and Reinforcement bar
There are reinforce square tube holding frame on the inside of the wall
Packing
Packaging of emergency shower room, tanks shower etc will be fumigation-free wooden crate or pallet.
Outside of the carton is wrapped with a special bubble film and firmly fixed with the pallet or crate to make sure it will not move toward any direction during the transportation.
